General information 1-11
7510
Registration
Sensor (registration)
The sensor (registration) is located just before the registration roll assembly can detect whether media exists in
the registration path.
Sensor (transparency detect)
This sensor is used to detect transparency media in order to automatically adjust feed speed, charge biases and
fuser temperatures.
Registration clutch
The registration clutch transmits the drive force of the K developer/transport drive motor to the registration roll
assembly.
Media transport roll assembly
The media transport roll assembly feeds paper from tray 2, tray 3 and tray 4 toward the registration roll
assembly.
Registration roll assembly
Statement 5.5 inches 8.5 inches
Universal
MPF only
140 to 297 mm
5.5 to 11.7 inches
105 to 305 mm
4.1 to 12 inches
98.4 to 432 mm
3.9 to 17 inches
148 to 482 mm
5.8 to 19 inches
7 3/4 Envelope 98.4 mm
3.875 inches
190.5 mm
7.5 inches
10 Envelope 104.8 mm
4.12 inches
241.3 mm
9.5 inches
DL Envelope 110 mm
4.33 inches
220 mm
8.66 inches
CS Envelope 162 mm
6.38 inches
229 mm
9.01 inches
Other Envelope 89 mm to 297 mm
3.5 to 11.7 inches
98.4 to 431 mm
3.8 to 17 inches
Transparencies (Letter and A4) 8.5 inches
210 mm
11 inches
297 mm
Media Width Length
