Lexmark 940e - X Color Laser Service Manual

2-158 Service Manual
7510
920.04 Main lamp warm up error
2
Check the fuser unit assembly for proper installation.
Is the fuser unit assembly installed properly?
Go to step 3. Install the fuser
unit assembly
properly.
3
Check the fuser unit assembly for proper connection.
Is the above component properly connected.
Go to step 4. Repair the
connection.
4
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the fuser
unit assembly.
Go to “Fuser unit
assembly
removal” on
page 4-15.
Problem solved.
Step Check Yes No
1 Check for proper voltage fuser.
Does the fuser unit assembly voltage match the voltage
required for the machine?
Go to step 2. Install the
appropriate
voltage fuser unit
assembly.
2
Check the fuser unit assembly for a media jam.
Is there a media jam in the fuser unit assembly?
Remove the
media.
Go to step 3.
3
Check the fuser unit assembly for proper installation.
Is the fuser unit assembly installed properly?
Go to step 4. Install the fuser
unit assembly
properly.
4
Check the fuser unit assembly for proper connection.
Is the above component properly connected.
Go to step 5. Repair the
connection.
5
Perform a print test.
Does the error continue?
Replace the fuser
unit assembly.
Go to “Fuser unit
assembly
removal” on
page 4-15.
Go to step 6.
Problem solved.
6
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the AC
drive card bracket
assembly.
Go to “AC drive
card bracket
assembly
removal” on
page 4-100.
Problem solved.
Step Check Yes No
