Lexmark 940e - X Color Laser Service Manual

Diagnostic information 2-75
7510
290.12 Sensor (ADF registration) late jam (side 2)
6
Check the ADF feed drive motor assembly for proper
operation.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF feed drv mtr.
Does the above component operate properly?
Replace the
ADF feed drive
motor assembly.
Go to “ADF
feed drive
motor
assembly
removal” on
page 4-134.
Go to step 7.
7
Check the ADF feed drive motor assembly for proper
connection.
Is the above component properly connected?
Replace the
ADF feed drive
motor assembly.
Go to “ADF
feed drive
motor
assembly
removal” on
page 4-134.
Replace the
connection.
8
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-138.
Go to step 9.
Problem solved.
9
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Problem solved.
Step Check Yes No
1 Check the original document condition.
Is the original document free of paper clips and staples as
well as damage such as creases, tears, holes or excessive
wear?
Go to step 2. Remove damaged
original document
and replace with a
new undamaged
original document.
Perform a ADF
test. If the problem
remains, go to step
2.
Step Check Yes No
