Lexmark 940e - X Color Laser Service Manual

Repair information 4-19
7510
Switch (printer left door interlock) removal
1. Remove the rear cover assembly. See “Rear cover assembly removal” on page 4-5.
Warning: Ensure that the rear left middle cover is removed before removing the rear left upper cover, or
damage will occur.
2. Remove the rear left middle cover. See “Rear left middle cover removal” on page 4-6.
3. Remove the rear left upper cover. See “Rear left upper cover removal” on page 4-7.
4. Remove the standard media exit shift assembly. See “Standard media exit shift assembly removal” on
page 4-17.
A
B
B
C
