Diagnostic information 2-77
7510
8
Check the ADF feed drive motor assembly for proper
connection.
Is the above component properly connected?
Replace the
ADF feed drive
motor assembly.
Go to “ADF
feed drive
motor
assembly
removal” on
page 4-134.
Replace the
connection.
9
Check the inverter solenoid assembly for proper operation.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Inverter solenoid.
Does the above component operate properly?
Go to step 11. Go to step 10.
10
Check the inverter solenoid assembly for proper connection.
Is the above component properly connected?
Replace the
inverter solenoid
assembly.
Go to “Inverter
solenoid
assembly
removal” on
page 4-139.
Replace the
connection.
11
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-138.
Go to step 12.
Problem solved.
12
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Problem solved.
Step Check Yes No
