Diagnostic information 2-81
7510
6
Check the ADF registration motor for proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF registration drv mtr.
5. Touch Forward or reverse.
Does the above component operate properly?
Go to step 8. Go to step 7.
7
Check the ADF registration motor for proper connection.
Is the above component properly connected?
Replace the ADF
registration motor.
Go to “ADF
registration
motor removal”
on page 4-159.
Replace the
connection.
8
Check the sensor (ADF registration) for proper operation.
Perform the sensor (ADF registration) test.
Open the ADF left cover assembly.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF registration.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 10. Go to step 9.
9
Check the sensor (ADF registration) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
registration).
Go to “Sensor
(ADF
registration)
removal” on
page 4-149.
Replace the
connection.
10
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-138.
Go to step 11.
Problem solved.
11
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Problem solved.
Step Check Yes No
