Lexmark 940e - X Color Laser Service Manual

2-84 Service Manual
7510
10
Check the inverter solenoid assembly for proper
operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Inverter solenoid.
Does the above component operate properly?
Go to step 12. Go to step 11.
11
Check the inverter solenoid assembly for proper
connection.
Is the above component properly connected?
Replace the
inverter
solenoid
assembly.
Go to “Inverter
solenoid
assembly
removal” on
page 4-139.
Replace the
connection.
12
Check the ADF registration motor for proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF registration drv mtr.
5. Touch Forward or reverse.
Does the above component operate properly?
Go to step 14. Go to step 13.
13
Check the ADF registration motor for proper connection.
Is the above component properly connected?
Replace the
ADF
registration
motor.
Go to “ADF
registration
motor
removal” on
page 4-159.
Replace the
connection.
14
Place an undamaged document in the ADF, and perform
a ADF test.
Does the error remain?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-138.
Go to step 15.
Problem solved.
Step Check Yes No
