Diagnostic information 2-227

7510

Check the printhead assembly.

Replace the printhead assembly.

Go to “Printhead assembly removal” on page 4-95.

Does the error continue?

Go to step 8. Problem solved.

Check the upper printer engine card assembly.

Replace the upper printer engine card assembly.

Go to “Upper printer engine card assembly

removal” on page 4-77.

Perform a print test.

Does the error continue?

Replace the RIP

card assembly.

Go to “RIP card

assembly

removal” on

page 4-73.

Problem solved.

Step Check Yes No
