3-14 Service Manual
7510
Available Bin Level Sensors
Available Media Path 1 Sensors
Available Media Path 2 Sensors
Available Booklet Path Sensors
Sensor Name
Finisher upper media bin full
Stacker bin level1
Stacker bin level2
Stacker bin upper limit
Stacker bin no media
Stacker bin level encod
Sensor Name
Bridge unit media entrance
Bridge unit media exit
Finisher media entrance
Bridge unit media bin exit
Buffer path
Upper media exit
Lower media exit
Compiler media in
De-curler cam HP
Sensor Name
Diverter gate
Front tamper hp
Rear tamper hp
Media eject clamp hp
Media eject shaft hp
Sensor Name
Booklet end guide HP
Booklet knife HP
Booklet knife folder
Booklet front tamper HP
Booklet rear tamper HP
Booklet unit media entrance
Booklet unit media exit
Booklet bin media present
Booklet compiler media present
