4-78 Service Manual

7510

13. Remove the NVM board (D) from the upper printer engine card assembly (B).

Replacement warning: When reinstalling the upper printer engine card assembly (B), ensure that the NVM

board (D) is installed on the new upper printer engine card assembly (B), or the machine may not function

properly.

Replacement warning: Ensure that the bridge card assembly (C) and the lower printer engine card (D) are

connected.

Note: Perform color registration adjustment.

Bottom view
