Parts catalog 7-37
7510
Assembly 32: Electrical 4
WARNING: In the event of replacement of any one of the following components:
• RIP card assembly
• Interconnect card assembly
Only replace one component at a time. Replace the required component, and perform a POR before replacing a
second component listed above. If this procedure is not followed, the printer will be rendered inoperable. Never
replace two or more of the components listed above without a POR after installing each one, or the printer will be
rendered inoperable.
WARNING: Never install and remove components listed above as a method of troubleshooting components.
Once a component has been installed in a machine, it cannot be used in another machine. It must be returned to
the manufacturer.
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X3804 1 1 RIP card cooling fan cover assembly (this comes assembled)
2 40X3807 1 1 RIP bridge card assembly
3 40X2359 1 1 Interconnect card assembly
4 40X5865 1 1 MFP RIP card assembly (X940e, X945e model)
4 40X4407 1 1 MFP RIP card assembly (XC940e, XC945e model)
5 40X3808 1 1 Upper printer engine card chassis assembly
6 40X4081 1 1 Upper printer engine card cable assembly
7 40X4151 1 1 Hard drive assembly includes:
• 2.5” 80GB hard drive
• Data cable
• Mounting bracket with hardware
8 40X2360 1 1 Fax interface card assembly
9 40X0507 1 1 Fax interface card cable assembly
