Parts catalog 7-41

7510

Assembly 35: ADF base

Asm

Index

Part

number

Units/

mach

Units/ kit

or pkg

Description

1 40X2257 1 1 ADF left hinge

2 40X3883 1 1 ADF registration pinch/frame assembly (this comes assembled)

3 40X2247 7 1 Large hook/loop strip

4 40X2330 5 1 Spring

5 40X2354 1 1 Registration pad

6 40X4104 1 1 Registration pad cover

7 40X2248 1 1 Solenoid/interlock cable assembly

8 40X2260 1 1 ADF controller card assembly

9 40X2259 1 1 ADF interface cable assembly

10 40X2258 1 1 ADF right hinge
