Parts catalog 7-45
7510
Assembly 37: ADF left cover components
Asm
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X2223 13 1 Sensor (pick roll position HP)
2 40X2291 3 4 Plastic ring clip 6 mm
3 40X2287 1 1 ADF feed/pick roll assembly (this comes assembled)
4 40X2276 1 1 Left cover pinch roll assembly (this comes assembled)
5 40X2274 1 1 ADF left cover handle
6 40X2381 1 1 Document set rear stop
7 40X2283 1 1 Document set actuator
8 40X2275 1 1 Sheet through actuator
9 40X2330 5 1 Spring
10 40X2277 1 1 Pick roll position motor assembly
11 40X2278 1 1 Pick roll position cable assembly
12 40X2321 1 1 Left cover media guide
13 40X2279 1 1 Document set front stop
