Parts catalog 7-47

7510

Assembly 38: ADF media guide

Asm

Index

Part

number

Units/

mach

Units/ kit

or pkg

Description

1 40X3890 1 1 Actuator/media guide assembly (this comes assembled)

2 40X2289 1 1 Inverter gate

3 40X2288 1 1 ADF main feed cable assembly

4 40X2223 1 1 Sensor (ADF pre-registration)

5 40X0589 1 1 Sensor (ADF registration)

6 40X2223 13 1 Sensor (ADF width APS 1)

7 40X2223 13 1 Sensor (ADF width APS 2)

8 40X2223 13 1 Sensor (ADF width APS 3)

9 40X2223 13 1 Sensor (ADF inverter)

10 40X3889 2 1 Media scan guide spring

11 40X3888 1 1 Media scan guide

12 40X2286 1 1 Switch (ADF left cover interlock)
