Parts catalog 7-77

7510

Assembly 57: 3TM left door

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X3818 1 1 Tray 2 feed-out sensor cable assembly

2 40X3817 1 1 Sensor (tray 2 feed-out)

3 40X3821 1 1 Switch (tray module left door interlock)

4 40X3819 1 1 Tray 3/4 feed-out sensor actuator

5 40X3820 2 1 Sensor (tray 3 feed-out)

6 40X3820 2 1 Sensor (tray 4 feed-out)

7 40X3816 1 1 3TM left door assembly (this comes assembled)

8 40X4035 2 1 Tray 3/4 feed-out sensor cable assembly

9 40X4119 3 1 Tray module media transport roll assembly
