7-84 MFP Service Manual

7510

Assembly 61: TTM tray 3

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X0711 2 1 TTM tray separation pad

2 40X3832 1 1 TTM tray 3 front cover

3 40X4126 4 1 TTM tray lift idler pulley

4 40X4127 4 1 TTM tray lift idler pulley guide

5 40X4084 4 1 TTM tray 3 lift cable

6 40X0708 2 1 TTM large idler pulley kit

• TTM large idler pulley

• TTM large idler pulley guide

7 40X3834 2 1 TTM tray 3 slide strip

8 40X3835 2 1 TTM tray 3 slide button
