LMI Technologies Gocator 2300 Series User Manual

Gocator 2300 & 2880 Series
Gocator Web Interface • Measurement • 169
Measurement Illustration
Height
Measures the height of a strip.
X
Measures the X position of a strip.
Z
Measures the Z position of a strip.
Parameter Description
Base Type Affects detection of rising and falling edges.
When Base Type is set to Flat, both strip (raised area)and base support regions are
needed. When set to None, only a point that deviates from a smooth strip support
region is needed to find a rising or falling edge.
Parameters
