Operating elements for driving
3.2 Brief description of the operating elements
Operating Instructions GMK5250L 3 302 633 en 3 - 65
27.09.2017
Steering system warning
CCS display
Automatic separate steering for driving around corners on/off
Separate steering for crab travel mode Automatic on/off
Manual separate steering on/off
When separate steering is switched on, the speed is limited to approx.
5km/h (3 mph).
s
–On: Steering system faulty – stop immediately,
Display symbol (1) – 4th and 5th axle cannot be steered; if
it is possible, it can only be steered in straight running
position – max 20 km/h (12 mph)
– Off: No error in the steering system
After engine start;
à p. 4 - 17
While driving;
à p. 5 - 35
– To switch on: Select symbol (1) and confirm – Symbol (2) is displayed
– To switch off: Select symbol (1) and confirm again – Symbol (3) is
displayed – Normal steering on
à p. 5 - 59
– To switch on: Select symbol (1) and confirm – Symbol (2) is displayed
– To switch off: Select symbol (1) and confirm again – Symbol (3) is dis-
played – Normal steering on
à p. 5 - 59
– To switch on: Select symbol (1) and confirm – Symbol (2) is displayed
– To switch off: Select symbol (1) and confirm again – Symbol (3) is
displayed – Normal steering on
à p. 5 - 59
