Manitowoc Grove GMK 5250L User Manual

Operating elements for crane operation
8.2 Brief description of the operating elements
8 - 122 3 302 633 en Operating Instructions GMK5250L
27.09.2017
Telescoping cylinder in the telescopic section display
Displayed telescopic section, e.g. telescopic section 1
Telescoping direction display
Telescope diagram display
Current relation of the telescopic sections to each other – section of top
view.
1 Start with
Retract
2 Start with Extend
à p. 10 - 110
Locking pin Display 1 and 2
1 On the telescopic section – Green: Locked
2 On the telescoping cylinder –Yellow: Intermediate position
3 Error –Red: Unlocked
à p. 10 - 101
