12.5 FREQROL Inverter Parameter List
Adjustment
function
−−
820 Speed control P gain 1
−−
821 Speed control integral time 1
822 Speed setting filter 1
824 Torque control P gain 1
825 Torque control integral time 1
826 Torque setting filter 1
827 Torque detection filter 1
828 Model speed control gain
830 Speed control P gain 2
831 Speed control integral time 2
832 Speed setting filter2
834 Torque control P gain 2
835 Torque control integral time 2
836 Torque setting filter2
837 Torque detection filter 2
Torque bias
849 Analog input off set adjustment
850 Control operation selection
858 Terminal 4 function assignment
859 Torque current 859 Torque current
860 Second motor torque current
−−
862 Notch filter time constant
863 Notch filter depth
864 Torque detection
865 Low speed detection
Indication
function
866 Torque monitoring reference
− 867 AM output filter 867 AM output filter
−− − 868 Terminal 1 function assignment
Protective
Functions
872
Input phase failure protection
selection
872
Input phase failure protection
selection
872
Input phase loss protection
selection
−−
874 OLT level setting
−−
875 Fault definition
Control sys-
tem functions
877
Speed feed forward control/
model adaptive speed control
selection
878 Speed feed forward filter
879 Speed feed forward torque limit
880 Load inertia ratio
881 Speed feed forward gain
Regeneration
avoidance
function
882
Regeneration avoidance
operation selection
882
Regeneration avoidance
operation selection
882
Regeneration avoidance
operation selection
883
Regeneration avoidance
operation level
883
Regeneration avoidance
operation level
883
Regeneration avoidance
operation level
884
Regeneration avoidance at
deceleration detection sensitivity
884
Regeneration avoidance at
deceleration detection sensitivity
−−
885
Regeneration avoidance
compensation frequency limit
value
885
Regeneration avoidance
compensation frequency limit
value
885
Regeneration avoidance
compensation frequency limit
value
886
Regeneration avoidance voltage
gain
886
Regeneration avoidance voltage
gain
886
Regeneration avoidance voltage
gain
Free
parameter
888 Free parameter 1 888 Free parameter 1 888 Free parameter 1
889 Free parameter 2 889 Free parameter 2 889 Free parameter 2
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series
Function
Pr
No.
Name Pr No. Name
Pr
No.
Name
