12.5 FREQROL Inverter Parameter List
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
Communica-
tion
549 Protocol selection 549 Protocol selection 549 Protocol selection
550
NET mode operation command
source selection
550
NET mode operation command
source selection
550
NET mode operation command
source selection
551
PU mode operation command
source selection
551
PU mode operation command
source selection
551
PU mode operation command
source selection
Current
average
monitor
555 Current average time 555 Current average time 555 Current average time
556 Data output mask time 556 Data output mask time 556 Data output mask time
557
Current average value monitor
signal output reference current
557
Current average value monitor
signal output reference current
557
Current average value monitor
signal output reference current
− 563
Energization time carryingover
times
563
Energization time carrying-over
times
563
Energization time carrying-over
times
− 564
Operating time carrying−over
times
564
Operating time carrying-over
times
564
Operating time carrying-over
times
−− − 569 Second motor speed control gain −−
− 571 Holding time at a start 571 Holding time at a start 571 Holding time at a start
−− − 574 Second motor online auto tuning
−−
PID control
575
Output interruption detection
time
575
Output interruption detection
time
576
Output interruption detection
level
576
Output interruption detection
level
577 Output interruption release level 577 Output interruption cancel level
− 611 Acceleration time at a restart 611 Acceleration time at a restart 611 Acceleration time at a restart
−−−−−653 Speed smoothing control
−−−−−665
Reqeneration avoidance
frequency gain
−
−−
684 Tuning data unit switchover −−
− 800 Control method selection 800 Control method selection
Torque
command
803
Constant power range torque
characteristic selection
−−
804
Torque command source
selection
805 Torque command value (RAM)
806
Torque command value
(RAM,EEPROM)
Speed limit
807 Speed limit selection
808 Forward rotation speed limit
809 Reverse rotation speed limit
Torque limit
810
Torque limit input method
selection
811 Set resolution switchover
812 Torque limit level (regeneration)
813 Torque limit level (3rd quadrant)
814 Torque limit level (4th quadrant)
815 Torque limit level 2
816
Torque limit level during
acceleration
817
Torque limit level during
deceleration
Easy gain
tuning
818
Easy gain tuning response level
setting
819 Easy gain tuning selection
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series
Function
Pr
No.
Name Pr No. Name
Pr
No.
Name
