H-12
FX Series PLC User's Manual - Data Communication Edition
Programming Communication
2 System Configuration and Selection
2.2 Applicable FX PLC and Communication Equipment
FX2N
Standard built-in
port (8-pin MINI-
DIN)
50 m
(164' 0")
15 m
(49' 2")
15 m
(49' 2")
FX
1NC
Standard built-in
port (8-pin MINI-
DIN)
15 m
(49' 2")
FX
2NC
Standard built-in
port (8-pin MINI-
DIN)
15 m
(49' 2")
FX Series Communication equipment (option)
Total extension
distance
Check
FX 2N -422-BD
(8-pin MINI-DIN)
FX 2N -232-BD
(9-pin D-Sub)
FX 2N -CNV-BD FX 2NC -232ADP
(9-pin D-Sub)
FX 0N -232ADP
(25-pin D-Sub)
FX 2N -CNV-BD
+
+
FX 2NC -232ADP
(9-pin D-Sub)
FX 0N -232ADP
(25-pin D-Sub)
FX 2NC -232ADP
(9-pin D-Sub)
FX 0N -232ADP
(25-pin D-Sub)
