H-13
FX Series PLC User's Manual - Data Communication Edition
Programming Communication
2 System Configuration and Selection
2.2 Applicable FX PLC and Communication Equipment
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
FX3U
Standard built-in
port (8-pin MINI-
DIN)
When using channel 1 (ch 1)
50 m
(164' 0")
15 m
(49' 2")
5 m
(16' 4")
15 m
(49' 2")
When using channel 2 (ch 2)
15 m
(49' 2")
15 m
(49' 2")
FX Series Communication equipment (option)
Total extension
distance
Check
FX 3U -422-BD
(8-pin MINI-DIN)
ch1
FX 3U -232-BD
(9-pin D-Sub, male)
RD
SD
ch1
FX 3U -USB-BD
(MINI-USB B)
ch1
RD
SD
FX 3U -CNV-BD
+
FX 3U -232ADP(-MB)
(9-pin D-Sub, male)
ch1
+
FX 3U -232ADP(-MB)
(9-pin D-Sub, male)
ch2
RD
SD
ch1
FX
3U -  -BD
(Where  represents
232, 422, 485 and USB)
FX 3U -CNV-BD
+
ch1
+
FX 3U -232ADP(-MB)
(9-pin D-Sub, male)
ch2
FX 3U -  ADP(-MB)
(Where  represents
232 and 485)
