96 KByte Flash Module (S12FTMRG96K1V1)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 1011
Upon clearing CCIF to launch the Set User Margin Level command, the Memory Controller will set the
user margin level for the targeted block and then set the CCIF flag.
NOTE
When the EEPROM block is targeted, the EEPROM user margin levels are
applied only to the EEPROM reads. However, when the P-Flash block is
targeted, the P-Flash user margin levels are applied to both P-Flash and
EEPROM reads. It is not possible to apply user margin levels to the P-Flash
block only.
Valid margin level settings for the Set User Margin Level command are defined in Table 28-55.
Table 28-54. Set User Margin Level Command FCCOB Requirements
CCOBIX[2:0] FCCOB Parameters
000 0x0D
Flash block selection code [1:0]
. See
Table 28-34
001 Margin level setting.
Table 28-55. Valid Set User Margin Level Settings
CCOB
(CCOBIX=001)
Level Description
0x0000 Return to Normal Level
0x0001 User Margin-1 Level
1
1
Read margin to the erased state
0x0002 User Margin-0 Level
2
2
Read margin to the programmed state
Table 28-56. Set User Margin Level Command Error Handling
Register Error Bit Error Condition
FSTAT
ACCERR
Set if CCOBIX[2:0] != 001 at command launch
Set if command not available in current mode (see Table 28-27)
Set if an invalid FlashBlockSelectionCode[1:0] is supplied (See Table 28-34 )
Set if an invalid margin level setting is supplied
FPVIOL None
MGSTAT1 None
MGSTAT0 None
