84
Chapter2 Muting
F3SG-SR
User’s Manual
System Operation and Functions
Standard Muting mode
Exit-Only Muting mode
Position Detection Muting mode
Dynamic Muting
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
Setting the muting time limit to infinite may cause a failure of the muting sensors to go undetected, resulting in the F3SG-SR
in an unintended MUTING state. Conduct risk assessment analysis thoroughly before enabling this setting.
Setting the muting input time limit value (maximum) to infinite may cause a failure of the muting sensors to go
undetected, resulting in a failure of disabling the MUTING state. Conduct risk assessment analysis thoroughly before
enabling this setting.
Dynamic Muting can be used in conjunction with any of Standard, Exit-Only and Position Detection Muting modes.
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3.
Function Initial value Configurable value or numerical range
Muting zone Bottom beam All beams any beam in 1-beam increments
Top beam
T1
min: Muting input time limit value (minimum) 0.1 s 0.1 to 3.9 s in 0.1-s increments
T1
max: Muting input time limit value (maximum) 4 s 0.2 to 60 s in 0.1-s increments, or infinite
T2: Muting time limit 60 s 1 to 600 s in 1-s increments, or infinite
T3: Maximum allowable muting signal interruption 0.1 s 0.1 to 20 s in 0.1-s increments
Function Initial value Configurable value or numerical range
Muting zone Bottom beam All beams any beam in 1-beam increments
Top beam
T1
min: Muting input time limit value (minimum) 0.1 s 0.1 to 3.9 s in 0.1-s increments
T1
max: Muting input time limit value (maximum) 4 s 0.2 to 4 s in 0.1-s increments, or infinite
T2: Muting time limit 60 s 1 to 600 s in 1-s increments, or infinite
T3: Maximum allowable muting signal interruption 0.1 s 0.1 to 4 s in 0.1-s increments
T4: Muting end wait time 1 s 0.1 to 20 s in 0.1-s increments
T5: Exit-only muting delay time 4 s 4 to 20 s in 0.1-s increments
Function Initial value Configurable value or numerical range
Muting zone Bottom beam All beams any beam in 1-beam increments
Top beam
T1
max: Muting input time limit value(maximum) 4 s 0.2 to 60 s in 0.1-s increments, or infinite
T2: Muting time limit 60 s 1 to 600 s in 1-s increments, or infinite
T3: Maximum allowable muting signal interruption 0.1 s 0.1 to 4 s in 0.1-s increments
Function Initial value Configurable value or numerical range
Dynamic muting Disable Enable/Disable
Dynamic muting measurement time 3 s 1 to 25 s in 0.1-s increments
Number of dynamic muting allowable beams 1 0 to 5 in 1-beam increments
