12
Chapter1 Ratings and Specifications
F3SG-SR
User’s Manual
Overview and Specifications
1-5. Ratings and Specifications
Extension of the cable must be within a specified length. If it isn't, safety functions may not work
properly, resulting in danger.
1-5-1. F3SG-SR Series
The  in the model names indicate the protective heights in millimeters.
Model
F3SG-SRA-14
F3SG-SRB-14
F3SG-SRA-25
F3SG-SRB-25
F3SG-SRA-45
F3SG-SRB-45
F3SG-SRA-85
F3SG-SRB-85
Performance Object resolution
(Detection capability)
Opaque objects
14-mm dia. 25-mm dia. 45-mm dia. 85-mm dia.
Beam gap 10 mm 20 mm 40 mm 80 mm
Number of beams 15 to 199 8 to 124 6 to 38 4 to 12
Lens size 4.4  3.4 mm (W  H) 6.7  4.5 mm (W  H)
Protective height 160 to 2,000 mm 160 to 2,480 mm 240 to 1,520 mm 280 to 920 mm
Operating
range
Long 0.3 to 10.0 m * 0.3 to 20.0 m
Short 0.3 to 3.0 m * 0.3 to 7.0 m
* When operating at an ambient temperature of -10 to -30°C, use the F3SG-SR with the operating range
of 0.3 to 5.0 m in Long Mode and 0.3 to 1.5 m in Short Mode.
Response time
*1
Normal
mode
ON to
OFF
Optical
synchronization:
8 to 18 ms
Wired
synchronization:
10 to 21 ms
Optical
synchronization:
8 to 13 ms
Wired
synchronization:
10 to 17 ms
Optical synchronization: 8 ms
Wired synchronization: 10 ms
OFF
to ON
Optical
synchronization:
40 to 90 ms
Wired
synchronization:
50 to 105 ms
Optical
synchronization:
40 to 65 ms
Wired
synchronization:
50 to 85 ms
Optical synchronization: 40 ms
Wired synchronization: 50 ms
×2 Slow
mode *2
ON to
OFF
Optical
synchronization:
16 to 36 ms
Wired
synchronization:
20 to 42 ms
Optical
synchronization:
16 to 26 ms
Wired
synchronization:
20 to 34 ms
Optical synchronization: 16 ms
Wired synchronization: 20 ms
OFF
to ON
Optical
synchronization:
80 to 180 ms
Wired
synchronization:
100 to 210 ms
Optical
synchronization:
80 to 130 ms
Wired
synchronization:
100 to 170 ms
Optical synchronization: 80 ms
Wired synchronization: 100 ms
×4 Slow
mode *2
ON to
OFF
Optical
synchronization:
32 to 72 ms
Wired
synchronization:
40 to 84 ms
Optical
synchronization:
32 to 52 ms
Wired
synchronization:
40 to 68 ms
Optical synchronization: 32 ms
Wired synchronization: 40 ms
OFF
to ON
Optical
synchronization:
160 to 360 ms
Wired
synchronization:
200 to 420 ms
Optical
synchronization:
160 to 260 ms
Wired
synchronization:
200 to 340 ms
Optical synchronization: 160 ms
Wired synchronization: 200 ms
