197
F3SG-SR
User’s Manual
Chapter4 Changing Settings with SD Manager 3
Setting with SD Manager 3
E
4-3-3-2. Designated Beam Output
First, carry out 4-3-1. Preparing to Change Settings.
Next, click the icon below on the Top page.
The setting screen below is displayed.
Select [Designated beam output information] for the output operation mode of the auxiliary output.
In the following example, the designated beam output information is assigned to the output operation
mode of the auxiliary output.
When [Designated beam output information] is selected for Auxiliary Output at the same time, the area configured is the
same for all these outputs.
To Next Page
