Chapter2 Maintenance Information
F3SG-SR
User’s Manual
System Operation and Functions
2-26. Maintenance Information
2-26-1. Overview
You can use the SD Manager 3 or SD Manager 3 Mobile APP to read the maintenance information of
F3SG-SR to view on a PC screen. The Maintenance Information function indicates the following
information:
• Error Log
• Warning Log
• Power-On Time *
• Load Switching Frequency *
• Muting Statistics Information
* The setting parameters of power ON time threshold and load switching frequency threshold cannot be changed using SD
Manager 3 Mobile APP.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more information on
setting this function by the SD Manager 3.
2-26-2. Error Log
The user can view details of errors occurred in the past. The error information is recorded in the F3SG-
SR main unit every 15 minutes. The displayed information is useful for troubleshooting. Up to 50 past
errors can be recorded. The information is displayed for the emitter and receiver, respectively.
2-26-3. Warning Log
The user can view details of the following warnings occurred in the past. The warning information is
recorded in the F3SG-SR main unit every 15 minutes. The displayed information can be used for
troubleshooting. Up to 50 past warnings can be recorded. The information is displayed for the emitter
and receiver, respectively.
• Muting sequence error
• Interlock sequence error
• Interference/vibration information
F3SG-SRA
F3SG-SRB
