102
Chapter2 Reduced Resolution
F3SG-SR
User’s Manual
System Operation and Functions
 Detection capability
Detection capability for the F3SG-SR differs based on the number of floating beams as shown below.
 LED indicator status
When the Reduced Resolution is being enabled, the CFG indicator turns on.
Refer to 2-1. Combination of Functions for more information on the use in conjunction with other functions.
2-17-2. Factory Default Setting
Reduced Resolution is disabled.
2-17-3. Setting with Intelligent Tap
The user cannot make any changes to the settings of this function by DIP Switch on the Intelligent Tap.
Model
Number of blocked
beams configured
Detection capability
Number of blocked
beams to turn safety
outputs OFF
Maximum diameter
that does not turn off
the safety outputs in
the detection zone
F3SG-SR-14
- 14 mm 1 beam -
1 beam 24 mm 2 beams 6 mm
2 beams 34 mm 3 beams 16 mm
3 beams 44 mm 4 beams 26 mm
F3SG-SR-25
- 25 mm 1 beam -
1 beam 45 mm 2 beams 15 mm
2 beams 65 mm 3 beams 35 mm
3 beams 85 mm 4 beams 55mm
F3SG-SR-45
- 45 mm 1 beam -
1 beam 85 mm 2 beams 35 mm
2 beams 125 mm 3 beams 75 mm
3 beams 165 mm 4 beams 115 mm
F3SG-SR-85
- 85 mm 1 beam -
1 beam 165 mm 2 beams 75 mm
2 beams 245 mm 3 beams 155 mm
3 beams 325 mm 4 beams 235 mm
