119
F3SG-SR
User’s Manual
Chapter2 Incident Light/Ambient Light
System Operation and Functions
E
2-25. Incident Light/Ambient Light
2-25-1. Incident Light Level Information
2-25-1-1. Overview
The user can use the SD Manager 3 or SD Manager Mobile APP to read incident light level of the
F3SG-SR and view on a screen. This function allows beam adjustment while checking incident light
level.
2-25-1-2. Setting with SD Manager 3
The user can enable this function to retrieve incident light level information. Making any changes to the
function is not possible. (When the F3SG-SR is in the cascade connection, incident light level of each
segment can be retrieved.)
2-25-2. Ambient Light Level Information
2-25-2-1. Overview
The user can use the SD Manager 3 or SD Manager Mobile APP to read incident light level of ambient
light from a photoelectric sensor or another F3SG-SR unit in a close area and view it on a screen. This
function allows the user to identify a photoelectric sensor radiating ambient light or beams being
affected by the light.
2-25-2-2. Setting with SD Manager 3
The user can enable this function to retrieve ambient light level information. Making any changes to the
function is not possible. (When the F3SG-SR is in the cascade connection, ambient light level of each
segment can be retrieved.)
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3 or SD
Manager Mobile APP.
F3SG-SRA
F3SG-SRB
To Next Page
