Chapter2 Pre-Reset
F3SG-SR
User’s Manual
System Operation and Functions
2-9-3. Setting with Intelligent Tap
Configuring the Positions 4 and 5 of the DIP Switch on the Intelligent Tap as Pre-Reset enables the
Pre-Reset mode. Refer to 3-4. LED Indicators on Intelligent Tap for more information.
When the Pre-Reset mode is configured, the function is activated with the following conditions:
• Minimum pressing time of the reset switch and pre-reset switch *1: 100 ms (factory default setting)
• Maximum number of times the F3SG-SR can be blocked after input of PRE-RESET signal *2: Infinite
(factory default setting) (The F3SG-SR must be blocked at least once.)
• Maximum permissible time from input of PRE-RESET signal to input of RESET signal *3: 8 s (factory
default setting)
*1 By using SD Manager 3, this parameter can be set by 100 ms in a range of 100 to 500 ms. (The minimum pressing time of the
pre-reset switch is equal to that of reset switch.)
*2 By using SD Manager 3, this parameter can be set to no limit or 1 to 9 times by one time.
*3 By using SD Manager 3, this parameter can be set by 1 s in a range of 8-60 s.
Make sure the Position 2 of the DIP Switch is set at ON (DIP Switch Enabled) to activate the settings by the DIP Switch.
Refer to Chapter 3 Setting with Intelligent Tap for more information on setting this function by the DIP Switch on the
Intelligent Tap.
2-9-4. Setting with SD Manager 3
The user can make changes to the settings of this function by the SD Manager 3.
* Set the minimum pressing time of the reset switch and pre-reset switch. The same minimum pressing time is applied to both
the switches.
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3.
Function Initial value Configurable value or numerical range
Pre-reset function Disabled Enabled/disabled
Maximum number of times F3SG can be
blocked
0 (infinite) 0 (infinite) / 1-9 times (by time)
Maximum permissible time from input of
PRE-RESET signal to input of RESET
signal (s)
8 s 1-60 s (by the second)
Minimum pressing time of reset switch * 100 ms 100-500 ms (by 100 ms)
