Omron F3SG-SRB Series User Manual

21
F3SG-SR
User’s Manual
Chapter1
List of Models
Overview and Specifications
E
1-6. List of Models
1-6-1. List of Models and Response Times
1-6-1-1. F3SG-SR
 Finger protection (Detection capability: 14-mm dia.)
Note 1. The maximum speed of movement of a test rod up to which the detection capability is maintained is 2.0 m/s.
Note 2. The response times are values when Scan Code is set at Code B. The response times for Code A are 1 ms shorter than
these values.
Refer to 2-3. Mutual Interference Prevention for more information.
Model
Number
of beams
Protective
height
[mm]
Response time
(Optical synchronization)
[ms]
Response time
(Wired
synchronization)
[ms]
ON to
OFF
OFF
(synchronized)
to ON
OFF (not
synchronized)
to ON
ON to
OFF
OFF to
ON
F3SG-4SR0160-14 15 160 8 40 140 10 50
F3SG-4SR0200-14-F 19 200 8 40 140 10 50
F3SG-4SR0240-14 23 240 8 40 140 10 50
F3SG-4SR0280-14-F 27 280 8 40 140 10 50
F3SG-4SR0320-14 31 320 8 40 140 10 50
F3SG-4SR0360-14-F 35 360 8 40 140 10 50
F3SG-4SR0400-14 39 400 8 40 140 10 50
F3SG-4SR0440-14-F 43 440 13 65 165 17 85
F3SG-4SR0480-14 47 480 13 65 165 17 85
F3SG-4SR0520-14-F 51 520 13 65 165 17 85
F3SG-4SR0560-14 55 560 13 65 165 17 85
F3SG-4SR0600-14-F 59 600 13 65 165 17 85
F3SG-4SR0640-14 63 640 13 65 165 17 85
F3SG-4SR0680-14-F 67 680 13 65 165 17 85
F3SG-4SR0720-14-F 71 720 13 65 165 17 85
F3SG-4SR0760-14-F 75 760 13 65 165 17 85
F3SG-4SR0800-14 79 800 13 65 165 17 85
F3SG-4SR0840-14-F 83 840 13 65 165 17 85
F3SG-4SR0880-14-F 87 880 13 65 165 17 85
F3SG-4SR0920-14-F 91 920 13 65 165 17 85
F3SG-4SR0960-14-F 95 960 13 65 165 17 85
F3SG-4SR1000-14 99 1000 13 65 165 17 85
F3SG-4SR1200-14 119 1200 13 65 165 17 85
F3SG-4SR1400-14 139 1400 13 65 165 17 85
F3SG-4SR1600-14 159 1600 18 90 190 21 105
F3SG-4SR1800-14 179 1800 18 90 190 21 105
F3SG-4SR2000-14 199 2000 18 90 190 21 105
