F3SG-SR
User’s Manual
Chapter2 Reduced Resolution
System Operation and Functions
E
2-17-4. Setting with SD Manager 3
The user can make changes to the settings of this function by the SD Manager 3.
*It is not possible to configure the Reduced Resolution function together with the Muting function. To
enable settings of the Reduced Resolution function, disable the Muting function.
In addition, setting parameters of the following functions is saved according to the states where the
Muting function is enabled and disabled, respectively. After changing the Muting function from Enable
to Disable or from Disable to Enable with the SD Manager 3, also check the settings of these
functions again.
Affected functions: External Device Monitoring (EDM), Start Interlock, Restart Interlock, Auxiliary
Output
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3.
Function name Initial value Configurable value or numerical range
Reduced Resolution Disable Enable*/Disable
Number of beams 1 1 to 3 beams in 1-beam increments
