56
Chapter2 External Device Monitoring (EDM)
F3SG-SR
User’s Manual
System Operation and Functions
2-11-4. Setting with SD Manager 3
The user can make changes to the settings of this function by the SD Manager 3.
* Setting parameters of this function is saved according to the states where the Muting function is enabled and disabled,
respectively. After changing the Muting function from Enable to Disable or from Disable to Enable with the SD Manager 3, also
check the settings of this function again.
Refer to Considerations for enabling and disabling Muting function with SD Manager 3 under 2-1. Combination of
Functions for more information.
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
After you make any change to the setting, verify that the F3SG-SR goes to the LOCKOUT state when the F3SG-SR is
wired in such a way that the specified voltage is applied directly to the RESET line of the receiver without the NC contact
of an external device.
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3.
Function
Initial value
Configurable value or numerical range
Muting function enabled* Muting function disabled*
EDM Disable Disable Enable/Disable
Allowable delay time 0.3 s 0.3 s 0.1 to 4 s in 0.1-s increments
