Omron F3SG-SRB Series User Manual

153
F3SG-SR
User’s Manual
Chapter3 IO-Link
Setting with Intelligent Tap
E
3-9-4. Service Data
Index Sub-Index Name R/W Length Setting contents
16 0 Vendor Name R 64 bytes "OMRON Corporation" (17bytes)
17 0 Vendor Text R 64 bytes "OMRON Corporation" (17bytes)
18 0 Product Name R 64 bytes "F39-SGIT-IL3 " (30bytes)
20 0 Product text R 64 bytes "Intelligent Tap" (15bytes)
21 0 Serial Number R 10 bytes Intelligent Tap's Serial Number(8 characters and 2
spaces)
22 0 Hardware Version R 5 bytes Intelligent Tap's Hardware Version XX.XX (5characters)
23 0 Firmware Version R 5 bytes Intelligent Tap's Firmware Version XX.XX (5characters)
24 0 Application Specific
Tag
R/W 32 bytes initial value: ******************************** (32 asterisks)
40 0 Process- DataInput R 4 bytes 16-31bit: Power supply
15 bit: Reserved (0)
14 bit: Instantaneous Block Detection Information (Channel 3)
13 bit: Instantaneous Block Detection Information (Channel 2)
12 bit: Instantaneous Block Detection Information (Channel 1)
11 bit: Light level diagnosis information (Channel 3)
10 bit: Light level diagnosis information (Channel 2)
9 bit: Light level diagnosis information (Channel 1)
8 bit: Sequence error information
7 bit: Sensor or Intelligent Tap lockout information
6 bit: Intelligent Tap Lockout Information
5bit: Reserved (0)
4 bit: Reset/EDM/Override input status
3 bit: Mute B input status
2 bit: Mute A input status
1 bit: Auxiliary output status
0 bit: Safety output status
64
(Primary
sensor
Receiver)
1 Supplier R 17 bytes OMRON Corporation
0 if SLC is not connected
2 Product name R 30 bytes F3SG-XXXX
0 if SLC is not connected
3 Serial Number R 10 bytes Serial Number
0 if SLC is not connected
4 Hardware Version R 5 bytes Hardware Version XX.XX (5characters)
0 if SLC is not connected
5 Firmware Version R 5 bytes Firmware Version XX.XX (5characters)
0 if SLC is not connected
65
(SLC's 2nd
Receiver)
1 Supplier R 17 bytes OMRON Corporation
0 if SLC is not connected
2 Product name R 30 bytes F3SG-XXXX
0 if SLC is not connected
3 Serial Number R 10 bytes Serial Number
0 if SLC is not connected
4 Product version
(Hardware)
R 5 bytes Hardware Version XX.XX (5characters)
0 if SLC is not connected
5 Product version
(Firmware)
R 5 bytes Firmware Version XX.XX (5characters)
0 if SLC is not connected
