Omron F3SG-SRB Series User Manual

268
Chapter5 Dimensions
F3SG-SR
User’s Manual
Wiring and Installation
5-2-2-4. Adjustable Top/Bottom Bracket (F3SG-RA/RE Adapter) (F39-
LSGTB-RE, sold separately)
5-2-2-5. Adjustable Top/Bottom Bracket (MS4800, F3SR Adapter) (F39-
LSGTB-MS, sold separately)
R4.1
R3.3
4.6
47.7
12
3.2
147.2
9.5
32
39.2
15
20
22.2
Material: High rolled steel (SPHC)
[ Unit : mm ]
R3.4
R3.4
R3.4
Material: High rolled steel (SPHC)
4.6
47.7
12
3.2
154
46
18.4
32
23.2
38.1
52.8
[ Unit : mm ]
