217
F3SG-SR
User’s Manual
Chapter4 Changing Settings with SD Manager 3
Setting with SD Manager 3
E
4-3-5. Operating State Setting
4-3-5-1. Response Time Change
First, carry out 4-3-1. Preparing to Change Settings.
Next, click the icon below on the Top page.
The setting screen below is displayed.
For more information on response time adjustment, refer to 2-21. Response Time Adjustment.
When changing the settings is complete, confirm the settings and write the configuration to the F3SG-SR.
For more information on safety distance calculation, refer to 5-1-2. Safety Distance.
When changing the settings is complete, confirm the settings and write the configuration to the F3SG-SR.
To enable the written configuration, refer to 4-2-7-3. Writing Configuration into Intelligent Tap.
When connecting the Intelligent Tap to a F3SG-SR and trying to return the F3SG-SR to [Detecting], follow step 4 of
4-1-3-2. Connection Procedure When Using USB Connector to restart the F3SG-SR and Intelligent Tap, or click the
[Monitor] button.
No. Function name Description Initial value Configurable value or numerical range
1 Response time
mode
Select a desired mode of the response
time.
Normal
mode
Normal mode/2 times slow/4 times slow/
8 times slow
To Next Page
