F3SG-SR
User’s Manual
Chapter2 Override
System Operation and Functions
E
2-14-5. Setting with SD Manager 3
The user can make changes to the settings of this function by the SD Manager 3.
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
Setting the override time limit to infinite may cause a failure of disabling the OVERRIDE state when there is a failure of
the override input signal. Conduct risk assessment analysis thoroughly before enabling this setting.
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3.
Function Initial value Configurable value or numerical range
Override Enable Enable/Disable
Override input time limit 1 s 0.2 to 5 s in 0.1-s increments
Override time limit 600 s 1 to 600 s in 1-s increments, or infinite
