273
F3SG-SR
User’s Manual
Chapter5 Mounting
Wiring and Installation
E
5-3. Mounting
5-3-1. Mounting Method
You can mount the F3SG-SR in the following four ways.
· Mounting with Side-Mount Brackets (Intermediate Brackets) (F39-LSGF)
· Mounting with Adjustable Side-Mount Brackets (Intermediate Brackets) (F39-LSGA)
· Mounting with Adjustable Top/Bottom Brackets (F3SJ, F3SN Adapter) (F39-LSGTB-SJ) and Side-
Mount Brackets (Intermediate Brackets) (F39-LSGF)
· Mounting with Adjustable Top/Bottom Brackets (F3SJ, F3SN Adapter) (F39-LSGTB-SJ) and
Adjustable Side-Mount Brackets (Intermediate Brackets) (F39-LSGA)
The mounting method and the number of required brackets of the Adjustable Top/Bottom Bracket (F3SG-RA/RE
Adapter) (F39-LSGTB-RE) and the Adjustable Top/Bottom Bracket (MS4800, F3SR Adapter) (F39-LSGTB-MS) are the
same as those for the Adjustable Top/Bottom Bracket (F3SJ, F3SN Adapter) (F39-LSGTBSJ) described below.
5-3-2. Number of Brackets Required
The numbers of brackets required according to the protective heights of the sensor are as follows:
• Mounting with Side-Mount Brackets (Intermediate Brackets) (F39-LSGF)
* The number of brackets required to mount either one of emitter and receiver. The Side-Mount Brackets (Intermediate Brackets)
are included with the sensor.
• Mounting with Adjustable Side-Mount Brackets (Intermediate Brackets) (F39-LSGA)
* The number of brackets required to mount either one of emitter and receiver.
• Mounting with Adjustable Top/Bottom Brackets (F3SJ, F3SN Adapter) (F39-LSGTB-SJ) and Side-
Mount Brackets (Intermediate Brackets) (F39-LSGF)
*1. The number of brackets required to mount either one of emitter and receiver.
*2. The Side-Mount Brackets (Intermediate Brackets) are included with the sensor.
• Mounting with Adjustable Top/Bottom Brackets (F3SJ, F3SN Adapter) (F39-LSGTB-SJ) and
Adjustable Side-Mount Brackets (Intermediate Brackets) (F39-LSGA)
* The number of brackets required to mount either one of emitter and receiver.
Make sure that the F3SG-SR is securely mounted and its cables and connectors are properly connected.
Protective height Number of Side-Mount Brackets *
0160 to 1440 2
1520 to 2480 3
Protective height Number of Adjustable Side-Mount Brackets *
0160 to 0280 1
0320 to 1440 2
1520 to 2480 3
Protective height Number of Adjustable Top/Bottom Brackets *1 Number of Side-Mount Brackets *1*2
0160 to 0840 2 0
0880 to 1680 2 1
1760 to 2480 2 2
Protective height Number of Adjustable Top/Bottom Brackets * Number of Adjustable Side-Mount Brackets *
0160 to 0840 2 0
0880 to 1680 2 1
1760 to 2480 2 2
To Next Page
