Omron F3SG-SRB Series - Chapter2 System Operation and Functions

Chapter2 System Operation and Functions
29
F3SG-SR
User’s Manual
E
Chapter 2 System Operation and Functions
2-1. Combination of Functions 31
2-2. Operating States 33
2-3. Mutual Interference Prevention 35
2-4. PNP/NPN Selection 39
2-5. Self-Test 40
2-6. External Test 42
2-7. Lockout Reset 44
2-8. Interlock 45
2-9. Pre-Reset 48
2-10. PSDI 51
2-11. External Device Monitoring (EDM) 54
2-12. Auxiliary Output 57
2-13. Muting 61
2-14. Override 85
2-15. Fixed Blanking 90
2-16. Floating Blanking 96
2-17. Reduced Resolution 101
2-18. Warning Zone 104
2-19. Setting Zone Adjacency Conditions 108
2-20. Operating Range Selection 110
2-21. Response Time Adjustment 112
2-22. Area Beam Indicator (ABI) 113
2-23. Designated Beam Output 116
2-24. Stable Light Threshold Adjustment 118
2-25. Incident Light/Ambient Light 119
2-26. Maintenance Information 120
2-27. Operating Status Monitoring 123
