118
Chapter2 Stable Light Threshold Adjustment
F3SG-SR
User’s Manual
System Operation and Functions
2-24. Stable Light Threshold Adjustment
2-24-1. Overview
The threshold value to judge if the unblocked light quantity of a beam is stable or not can be changed.
The threshold value to judge as unblocked is equal to 100%.
The judging status of stable unblocking can be monitored by changing the threshold value according to
the operating environment and assigning the stable unblocking information to the auxiliary output and
the area beam indicator (ABI).
When the stable light threshold value is changed, the following threshold values of the output information are also
changed.
- Auxiliary Output: Stable-state information and Light level diagnosis information (upper limit)
- Area Beam Indicator: Stable-state information and Light level diagnosis information (upper limit)
- IO-Link Process Data: Light level diagnosis information (upper limit)
For the details of the information assigned to the auxiliary output, refer to 2-12. Auxiliary Output.
2-24-2. Factory Default Setting
The threshold value is set to 170%.
2-24-3. Setting Change using Intelligent Tap
It is unable to change the setting of this function using the DIP Switch of the Intelligent Tap.
2-24-4. Setting Change using SD Manager 3
The following setting can be made using SD Manager 3.
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
For the details of the setting change using SD Manager 3, refer to Chapter 4 Setting with SD Manager 3.
F3SG-SRA
F3SG-SRB
Function name Initial value Configurable value or numerical range
Stable light threshold 170% 100-300% (by 10%)
To Next Page
