59
F3SG-SR
User’s Manual
Chapter2 Auxiliary Output
System Operation and Functions
E
2-12-4. Setting with SD Manager 3
The user can make changes to the settings of this function by the SD Manager 3.
*1. Setting parameters of this function is saved according to the states where the Muting function is
enabled and disabled, respectively. After changing the Muting function from Enable to Disable or
from Disable to Enable with the SD Manager 3, also check the settings of this function again.
Refer to  Considerations for enabling and disabling Muting function with SD Manager 3 under 2-1. Combination of
Functions for more information.
Refer to 2-13. Muting for more information on settings of the Muting function.
*2. Refer to the table of Information (Output operation mode) assigned to auxiliary output below.
*3. Output signal is sent according to the patterns as shown in the output pattern chart below.
 Output pattern chart
Function
Initial value
Configurable value or numerical
range
Muting enabled * Muting disabled
Output operation mode Safety output information Safety output information *2
Inverted signal output Enable Enable Enable/Disable
Output pattern Solid-ON Solid-ON Solid-ON/ON 1 time *3
Solid-ON
ON 1 time
1 s
