Omron F3SG-SRB Series - Bracket; Side-Mount Bracket (Intermediate Bracket) (F39-LSGF); Adjustable Side-Mount Bracket (Intermediate Bracket) (F39-LSGA, Sold Separately); Adjustable Top;Bottom Bracket (F3 SJ, F3 SN Adapter) (F39-LSGTB-SJ, Sold Separately)

267
F3SG-SR
User’s Manual
Chapter5 Dimensions
Wiring and Installation
E
5-2-2. Bracket
5-2-2-1. Side-Mount Bracket (Intermediate Bracket) (F39-LSGF)
5-2-2-2. Adjustable Side-Mount Bracket (Intermediate Bracket) (F39-LSGA,
sold separately)
5-2-2-3. Adjustable Top/Bottom Bracket (F3SJ, F3SN Adapter) (F39-LSGTB-
SJ, sold separately)
13
5.7
14.7
30.7
34.4
13
8.2
30.7
6.5
41
37.5
12
6.3 dia.
6.3 dia.
Material:Zincalloy
[ Unit : mm ]
Material: Zinc alloy
6.3
13
10
26.5
56.5
44.1
6.3
13
73
20
26.7
56.5
12
38.5
[ Unit : mm ]
4.6
47.7
12
19
29
5.8
32
32
137
1.7
9 dia.
10
15.4
Material: High rolled steel (SPHC)
3.2
[ Unit : mm ]
