142
Chapter3 Teach-in (Fix Blanking / Floating Blanking)
F3SG-SR
User’s Manual
Setting with Intelligent Tap
3-7. Teach-in (Fix Blanking / Floating Blanking)
Make sure the Responsible Person test the operation of the F3SG-SR after setting with the
Teach-in to verify that the F3SG-SR operates as intended. Unintended settings may cause a
person to go undetected, resulting in serious injury.
3-7-1. Setting Fixed Blanking by Teach-in
Overview
You can teach-in the settings of the Fixed Blanking by interrupting the target area of the Fixed
Blanking. The Teach-in described in this chapter is performed with the Intelligent Tap connected to the
F3SG-SR and using the Push Switch or the Muting Input A.
Teach-in steps
Perform the Teach-in of the Fixed Blanking based on the following steps.
(1) Connect Intelligent Tap to F3SG-SR
(2) Beam Alignment
(3) DIP Switch Setting
(4) Transition to Teach-in Mode
(5) Teach-In and Check Processes
(6) Restart
(1) Connect Intelligent Tap to F3SG-SR
Connect the Intelligent Tap to the F3SG-SR.
(2) Beam Alignment
Perform the beam alignment for the F3SG-SR . In the case of the Optical Synchronization, install the
F3SG-SR so that the synchronization beams are clear. For detailed beam adjustment steps, see 5-3-5.
Beam Alignment Procedure.
Misalignment during the Teach-in may result in an unintended setting or a failure of the Teach-in.
The factory default setting of the Teach-in Input is [Enable Teach-in by Push Switch]. When selecting [Enable Teach-in
by Push Switch or wiring], select [Teach-in Input] – [Enable Teach-in by Push Switch or wiring] with the SD Manager 3
after the step (2), and then perform the Restoration.
The [Enable Teach-in by Push Switch or wiring] function cannot be used in combination of some functions. Refer to 2-1.
Combination of Functions for more information on combinations of functions.
Refer to 4-3-2-3. Teach-in Input for more information on setting this function by the SD Manager 3.
Refer to 4-2-7-3. Writing Configuration into Intelligent Tap for more information on the Restoration by the SD Manager 3.
F3SG-SRA X
F3SG-SRB X
To Next Page
