230
Chapter4 Monitoring with SD Manager 3
F3SG-SR
User’s Manual
Setting with SD Manager 3
4-4-3-2. Warning Log
This function can be used only when the F3SG-SR is connected to the Intelligent Tap and a PC.
Select [Warning Log] from the [Maintenance Information] list in the [Menu] window.
The screen below is displayed. Click a warning item you want to view and the cause and measures of the
warning item is displayed.
* The warning log information of the emitter is displayed only when the sensor is connected in the Wired Synchronization.
• Refer to 8-1-3. Warning for more information on the warning codes and descriptions.
• Refer to 2-26-4. Power-ON Time for more information on the accumulated power-on time.
• Warning logs are only displayed for a sensor segment selected in the Target sensor section.
• Up to 50 past warnings can be recorded. Up to last five logs are displayed without logging in.
• When the F3SG-SR is in a cascade connection, select a desired sensor segment from the [Target sensor]
button in the top right corner of the screen.
No. Function Description
1 Warning Log Information
(Receiver)
Shows warning logs including warning codes, warning descriptions and accumulated
power-on time at the time when warnings occurred, with the most recent warnings first for
the receiver.
2 Warning Log Information
(Emitter) *
Shows warning logs including warning codes, warning descriptions and accumulated
power-on time at the time when warnings occurred, with the most recent warnings first for
the emitter.
3 Show error descriptions Click an error or warning log to show details, cause and measures of the event.
4 Save maintenance
information
Saves error and warning logs, Intelligent Tap log, power-on time, accumulated power-on
time, load switching frequency and accumulated load switching frequency as a .csv file.
To Next Page
