117
F3SG-SR
User’s Manual
Chapter2 Designated Beam Output
System Operation and Functions
E
2-23-4. Setting with SD Manager 3
The user can make changes to the settings of this function by the SD Manager 3.
When outputting the light unblocked/blocked states of a designated beam, configure any one of the
output operation modes of auxiliary output or Area Beam Indicator (ABI) as designated beam output
information.
It is recommended that the Position 2 of the DIP Switch be set at OFF (DIP Switch Disabled).
Refer to Chapter 4 Setting with SD Manager 3 for more information on setting this function by the SD Manager 3.
Function Initial value Configurable value or numerical range
Designated beam output Disable Enable/Disable
Setting by Manual Manual/Teach-in
Designated beam zone Bottom beam - Any beam in 1-beam increments
Top beam -
Designated beam state Light-ON Light-ON/Dark-ON
