123
F3SG-SR
User’s Manual
Chapter2 Operating Status Monitoring
System Operation and Functions
E
2-27. Operating Status Monitoring
2-27-1. Overview
I/O information and the state of the F3SG-SR can be read out with the SD Manager 3.
Refer to Chapter 4 Setting with SD Manager 3 for more information on using this function by the SD Manager 3 or SD
Manager 3 Mobile APP.
2-27-2. Readout Information
The user can view the following information related to a receiver.
The information is displayed in a block in case of a cascade connection.
F3SG-SRA
F3SG-SRB
Information name Description
External wiring
information
Power Supply Displays a supply voltage being supplied
OSSD 1 (Black) Linked to OSSD 1 signal
OSSD 2 (White) Linked to OSSD 2 signal
RESET (Yellow) Linked to Reset/External Device Monitoring (EDM)/Override input
signal
AUX (Red) Linked to Auxiliary output signal
MUTE A (Gray) Linked to Muting input A/Pre-Reset/PSDI input
MUTE B (Pink) Linked to Muting input B
Sensor Information Scan code Displays Scan Code setting
EDM Displays EDM setting
Interlock/Pre-Reset/PSDI Displays Interlock/Pre-Reset/PSDI setting
Fixed/Floating Blanking Displays Fixed/Floating Blanking setting
PNP/NPN Displays output mode (PNP/NPN) setting
DIP Enable/Disable Displays whether the settings by the DIP Switches are enabled or
disabled.
Operating Status Muting information Linked to the MUTING state
Override information Linked to the OVERRIDE state
Sequence error information Linked to the MUTING SEQUENCE ERROR state or the INTERLOCK
SEQUENCE ERROR state
Safety output information Linked to safety output signal
Push-SW information Linked to the input signal of Push Switch on Intelligent Tap
Blanking beam unblocked
information
Linked to the state where the blanking beam is unblocked
