180
Chapter4 Basic Operation of SD Manager 3
F3SG-SR
User’s Manual
Setting with SD Manager 3
4-2-5. Logging In/Logging Out
4-2-5-1. Logging In
When reading or changing the configuration of the Intelligent Tap or F3SG-SR using SD Manager 3,
one of the following two access levels can be selected. Select the access level at which SD Manager 3
is used when logging in.
• Operator level: Only reading configuration information is available. (Only changing a power-on time
and load switching frequency thresholds is available.)
• Administrator level: Reading and changing configuration information is available.
When an Intelligent Tap is connected with F3SG-SR, if logging in, the F3SG-SR shifts to the setting
state and the safety output enters the OFF state.
The login operation can be executed even if position 2 of the DIP Switch on the Intelligent Tap is ON (DIP Switch
Enabled).
Select the [Login] button from the [Account] menu on the tool bar.
Or, click the [Login] button directly from the tool menu.
The following dialog is displayed.
No. Function Description
1 Access level Select either operator level or administrator level.
2 Enter your password Enter a password if you want to log in with the administrator level.
3 OK Enables the login at the selected level.
4 Cancel Cancels the login.
To Next Page
