Chapter1 Ratings and Specifications
F3SG-SR
User’s Manual
Overview and Specifications
1-5-3. Bluetooth
®
Communication Unit
*It depends on use environment conditions.
Connections To sensors, control box and IO-
Link
M12 connectors: 8-pin (CN1: receiver and CN2: control box) and 5-pin (CN3: IO-Link
and CN4: emitter), IP67 and IP67G (JIS C 0920 Annex 1) rated when mated.
The F3SG-SR meets the degree of protection when the root cable of the F3SG-SR is
correctly connected with the F3SG-SR.
Connection USB Type-C
TM
Cable extension 20 m max. between IO-Link Master and Intelligent Tap, 4 m max.* between PC and
Intelligent Tap via USB cable
* It is not guaranteed that the Intelligent Tap is connectable to any PC or USB cable.
Verify the connection with the USB cable you use.
IO-Link
communicati
ons
IO-Link version Version 1.1
Baud rate COM3: 230.4 kbps
Data length PD: 4 bytes, OD: 32 bytes (M-sequence type: TYPE_2_V)
Minimum cycle time 12 ms
Material PBT resin
Weight F39-SGIT-IL3: 180 g (when packaged), F39-LITF1: 50 g (when packaged)
Included accessories Instruction Sheet and M12 Connector Cover (2 pcs)
Model F39-SGBT
Applicable sensor
F3SG-SR Series
Power supply voltage (Vs)
24 VDC±20%, ripple p-p 10% max. (shares power supply of Intelligent Tap)
Current consumption
30 mA max. (shares power supply of Intelligent Tap)
Ambient temperature
Operating: -30 to 55 °C (non-icing)
Storage: -30 to 70 °C
Ambient humidity
Operating: 35% to 85% (non-condensing)
Storage: 35% to 85%
Degree of protection
IP65, IP67 and IP67G (rated when connected to Intelligent Tap)
Vibration resistance
10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps for all 3 axes
Shock resistance
100m/s
2
, 1000 shocks for all 3 axes
Type of connection
To be connected to Intelligent Tap
Communication system
Bluetooth
®
Version 3.0
Communication profile
SPP (Serial Port Profile)
Transmission distance
Approx. 10 m max. (Output power: Class 2) *
Material
PBT resin
Weight
70g (when packaged)
Model F39-SGIT-IL3
