Chapter4 Changing Settings with SD Manager 3
F3SG-SR
User’s Manual
Setting with SD Manager 3
For more information on auxiliary output, refer to 2-12. Auxiliary Output.
When changing the settings is complete, confirm the settings and write the configuration to the F3SG-SR.
To enable the written configuration, refer to 4-2-7-3. Writing Configuration into Intelligent Tap.
When connecting the Intelligent Tap to a F3SG-SR and trying to return the F3SG-SR to [Detecting], follow step 4 of
4-1-3-2. Connection Procedure When Using USB Connector to restart the F3SG-SR and Intelligent Tap, or click the
[Monitor] button.
Information (Output operation mode) assigned to Auxiliary output
*1. This parameter can be changed using SD Manager 3. For details, refer to 4-3-5-2. Stable Light Threshold Adjustment.
*2. The function can be configured even when no secondary sensor (Channel 2 or Channel 3) is connected. In that case, the
safety outputs of the secondary sensor (Channel 2 or Channel 3) are regarded as the OFF state.
Information Name Description
Safety output information When Safety output is in the ON state
Interlock information Under INTERLOCK state
Lockout information Under error/ LOCKOUT state
Excess power-on time information When power-on time exceeds power-on time threshold
Excess load switching frequency information
When load switching frequency exceeds load switching frequency threshold
Stable-state information When light intensity, which is constantly monitored, is 170% or higher
(changeable *1) of ON-threshold
Muting information Under Muting state
Override information Under Override state
Muting/Override information Under either Muting or Override state
Light level diagnosis information
When the F3SG-SR is unblocked and light intensity is within a range from 100%
to 170% of ON-threshold for 10 s or longer
Warning zone information When warning zone is blocked
Blanking bream unblocked information When Fixed-Blanking or Floating Blanking beams are unblocked
PSDI Information When the F3SG-SR is ready to be blocked for feeding or removing parts
Troubleshooting support signal When one of the signals of Sequence error information, Interference/vibration
information and Light level diagnosis information is in the ON state.
Designated beam output information When a designated beam is blocked or unblocked
Sequence error information Under Muting sequence error state or Interlock sequence error state
Reset-input information When Reset/EDM/Override input is in the ON state
Mute A input information When muting input A is in the ON state
Mute B input information When muting input B is in the ON state
EDM input information When EDM signal input is in the ON state
Individual cascaded sensor output (Channel 1) When Safety output of Primary sensor in cascade connection is the ON state
Individual cascaded sensor output (Channel 2) *2
When Safety output of 1st Secondary sensor in cascade connection is the ON state
Individual cascaded sensor output (Channel 3) *2
When Safety output of the 2nd Secondary sensor in cascade connection is the ON state
Blanking/Warning-zone information When Fixed Blanking, Floating Blanking, Reduced Resolution or Warning Zone
function is enabled
Instantaneous block information When the F3SG system stops accidentally due to interference or vibration. (In
case of cascade connection, when any of cascaded segments comes under
this condition.)
Pre-reset Information Under Pre-reset state
Communication quality diagnosis information
Under communication retry state due to noise or communication cable short-circuit
Recoverable error information Under recoverable error state
Replacement-recommended error information
Under replacement-recommended error state
None (OFF) Disables the function.
